Sealing Plugs for operating pressure up to 450 bar
MB 600-120
MB series
Expansion and anchorage of sleeve in hole wall is achieved by pressing the ball into sleeve. The MB series plug is designed for use in base materials of both low to high hardness.
Technical Specification
Min. l3
12.8 mm
Sleeve material
Stainless steel
Ball material
Stainless steel
3D-Data available
Order description
MB 600-120
d1
12.0 mm
l1
13.0 mm
l2 ~
17.80 mm
d2
+0.1
0
12.0 mm
Max. d3
10.6 mm
x ±0.2
0.4 mm
Surface
Sleeve and ball clear passivated per MIL S 5002, aerospace quality
Packaging unit
25 / 100
MB 600 120_en
